20E Facial Recognition Outdoor Panel
Taichuan 20E Facial Recognition Outdoor Station provides robust security while acting as the intelligent protector of your home. You have the flexibility to choose your preferred unlocking method, be it face access, card swiping, password entry, or mobile app. It offers improved safety and privacy protection, making your home life both more convenient and secure!
Choosing your preferred unlocking methods
This product offers multiple layers of protection, ensuring convenience, speed, security, and peace of mind.
HD Dual Camera
The product provides super clear image quality that remains clear day and night, ensuring reliable recognition and peace of mind in your daily life.
System Diagram
| Specifications | |
| Model | TC-5000D-20E |
| System | |
| OS | Android 7.1 |
| CPU | Dual-core Cortex-A72 + Quad-core Cortex-A53 |
| RAM/ROM | 2G / 8G |
| Master Frequency | 1.8GHZ |
| Camera | |
| Image Sensor | Dual camera (color HD camera plus infrared HD camera)/CMOS 2MP HD Colorful Camera |
| Supplement Light | White LEDs |
| Viewing Angle | Horizontal: 115° Vertical: 90° |
| Display | |
| Screen | 10 " TFT High definition IPS display screen, Fully fitted |
| Resolution Ratio | 1280*800 |
| Operation | Touch Screen |
| Color | Silver+Black |
| Audio | |
| Input | Built-in Microphone |
| Output | Built-in Loudspeaker |
| Codec | G.711 U |
| Compression Rate | 64 kbps |
| Audio Quality | Noise Suppression & Echo Cancellation |
| Network | |
| Ethernet | RJ45, 10/100 Mbps adaptive |
| Protocol | TCP/IP |
| PoE | IEEE802.3af/at |
| Alarm Input | Alarm IN : Alarm / DOOR IN : Unlock Detection |
| Relay Output | COM / NO |
| RS485 | GND / A / SV / B |
| TF Card | Micro SD Card |
| General | |
| Power Supply | DC 12V Connector / POE |
| Operating Temperature | -25。C ~ +70。C |
| Operating Humidity | 10~93% |
| Application Environment | Outdoor |
| IP Protection | IP54 |
| Installation | Wall |
| Dimension (WxHxD) | 176*337*34.4(mm) |
| Embeddedsize (WxHxD) | 158*328*43mm |
| Material | Tempered glass panel + Aluminum alloy body + Sheet metal bottom shell |
| Door Lock | Relay Unlock(COM / +12V / NO / GND) |
